Description
The ATI 4590 is a high-performance pressure mid-high frequency driver designed to deliver exceptional sound quality for professional audio applications.
- Throat: The driver features a 2-inch throat, optimizing sound dispersion for clearer audio reproduction.
- Nominal Impedance: It has a nominal impedance of 8 Ohms, ensuring compatibility with a wide range of amplifiers and audio equipment.
- Middle Range (AES): The driver handles up to 150 watts in the middle-frequency range (AES), making it capable of delivering powerful and accurate sound reproduction.
- High Range (AES): In the high-frequency range, the ATI 4590 can handle up to 80 watts (AES), providing crisp, detailed high-end performance.
- Sensitivity: With a sensitivity of 118Ā±2dB, the driver ensures loud, efficient output while maintaining precision in audio clarity.
- Frequency Range: It offers a frequency range from 300 Hz to 20 kHz, capable of producing a broad spectrum of sound frequencies.
- Frequency Range (-10dB max): For a more extended range, the driver operates from 300 Hz to 9 kHz at -10dB max, ideal for specialized applications.
- Voice Coil Diameter: The driver is equipped with a 3.5-inch voice coil, contributing to its efficiency and thermal stability.
- Voice Coil Material: The voice coil is made from CCAW (Copper-Clad Aluminum Wire), providing a balance between performance and weight reduction.
- Former Material: The voice coil’s former is made from Kapton, a high-performance material known for its excellent thermal resistance and mechanical strength.
- Diaphragm Material: The diaphragm is crafted from polyester, ensuring durability and consistent performance over time.
- Magnet Type: The driver uses a strontium ferrite magnet, providing powerful magnetic flux for enhanced efficiency and sound reproduction.
