PA Amplifier 900 Watt Model ATI-901

MODEL ATI-901
4 OHMS EIA 1kHz 1%THD 900W
8 OHMS EIA 1kHz 1%THD 600W
8 OHMS BRIDGE 1800W
DISTORTION(SMPTE-1M) <0.1%
S/N RATIO >95dB
DAMPING FACTOR >450
CLASS AB
EIA Rack Space 2U
Dim.(WxHxD)mm 482*88*360
Weight (in kgs) 23Kgs
Share On
Technology
  • Voice Sugar

Description

ATI-901 PA Amplifier:

  • Power Output (4 Ohms, EIA 1kHz, 1% THD): The ATI-901 delivers a robust 900W of power at 4 Ohms with a 1% total harmonic distortion (THD) at 1kHz.
  • Power Output (8 Ohms, EIA 1kHz, 1% THD): At 8 Ohms, the amplifier provides 600W of clean power at 1kHz and 1% THD.
  • Bridged Power Output (8 Ohms): In bridged mode, the ATI-901 produces an impressive 1800W at 8 Ohms.
  • Distortion (SMPTE-1M): The amplifier maintains ultra-low distortion, with a value of less than 0.1%, ensuring clear and pristine audio performance.
  • Signal-to-Noise Ratio (S/N Ratio): With a signal-to-noise ratio of over 95dB, the ATI-901 ensures exceptional sound clarity with minimal background noise.
  • Damping Factor: The ATI-901 features a damping factor greater than 450, providing tight control over speaker movements and superior bass performance.
  • Amplifier Class: This model operates in Class AB mode, combining efficiency with high-quality sound reproduction.
  • EIA Rack Space: The ATI-901 occupies 2U of rack space, making it a compact yet powerful solution for professional audio setups.
  • Dimensions: The amplifier has a size of 482mm (W) x 88mm (H) x 360mm (D), making it suitable for standard rack installations.
  • Weight: Weighing in at 23kg, the ATI-901 strikes a balance between durability and portability, ideal for live events and installations.
