PA Amplifier 500 Watt Model ATZA 5000 BTE

Model: ATZA 5000 BTE
Power Output : 300 W + 300 W Max, 250 W + 250 W RMS at 10% THD, 180 W + 180 W RMS at 5 % THD, 165 W RMS at 2% THD
Output Regulation : 2 dB, no load to full load at 1 KHZ
Input Channels : Mono 6x Mic 0.6mV/4.7K2,2 x Aux 100 mV/470K, Stereo L/R 200 mV/100 KΩ, Line L/R 1V/50KΩ
Frequency Response : 50 – 15,000 Hz +-3DB
Signal to Noise Ratio : 600 dB
Tone Controls Bass : +-10dB at 100 Hz, Treble +- 10 dB at 10 KHZ
Outputs Preamp : 200 mV/6000, Line 1V/1KΩ
Speaker Outputs : 40.80.70 V & 100 V for each zone
Power Supply AC : 220 -240 V, 50/60 Hz DC: 24 V (2x12V Car Battery)
Power Consumption AC : 700 VA DC: 9A
Dimensions : W510 X H172 X D385 mm
Weight : 24.2 Kg

Share On

Description

Introducing the ATZA 5000 BTE, this powerhouse delivers a maximum output of 300W + 300W and maintains exceptional sound quality with 165W RMS at 2% THD.
Its output regulation ensures consistent performance, varying only 2 dB from no load to full load at 1 kHz.
It combines powerful output with a space-saving design, making it ideal for professional audio installations.
The amplifier features multiple input channels, including 6x Mic inputs and stereo L/R line inputs, providing flexibility for various audio sources.
The frequency response spans 50 to 15,000 Hz, delivering a wide range of sound, while the signal-to-noise ratio of 600 dB ensures minimal noise interference.
Seamless performance is ensured with advanced output regulation, maintaining consistent audio quality across all loads.
With precise tone controls for bass and treble, users can fine-tune the audio to their preference.
The preamp and line outputs offer versatile connectivity options. For speaker connections, the system supports 40V, 80V, 70V, and 100V outputs per zone.
The power supply is robust, supporting both AC 220-240V and DC 24V for flexibility in various environments.
Despite its power, the system remains efficient, with a power consumption of 700 VA on AC and 9A on DC.
The unit is compact yet sturdy, with dimensions of W510 x H172 x D385 mm and a total weight of 24.2 kg.
