ATI-80XT 80 Watt PA Driver Unit

Description

The ATI-80 XT 80 Watt PA Driver Unit is a powerful and versatile audio component designed to deliver high-performance sound in professional audio systems.

• Power: With a power rating of 80 W and a 100 V output, this driver unit is well-suited for a variety of PA applications, ensuring strong, clear sound.
• Power Tops: It offers adjustable power settings at 15 W, 30 W, 45 W, 60 W, and 80 W, allowing for flexible sound management depending on the needs of your setup.
• Frequency Response: The driver covers a frequency range of 160 Hz to 7,000 Hz, ensuring a broad range of audible frequencies are accurately reproduced for a rich sound experience.
• SPL at 1 kHz: With a SPL of 120 dB at 1 W and 1 m, and 140 dB at 80 W and 1 m, the ATI-80 XT is capable of producing high sound pressure levels suitable for large venues or outdoor events.
• Throat Coupling: The driver features a 1-3/8′ – 18 TPl throat coupling, providing a secure and reliable connection for optimal performance, with a Throat Couple No.1 designed for enhanced sound output.
• Dimensions: Measuring at 150 x 135 mm, the ATI-80 XT is compact enough for easy installation while still delivering robust audio performance.
• Weight: Weighing just 2.38 kg, the driver is lightweight for its power class, making it easy to handle and install without sacrificing performance.
