DJ Amplifier 7200 Watt Model ATI 30+

8Ω stereo power 2x1600W
4Ω stereo power 2x3000W
2Ω stereo power 2x3600W
8Ω Bridge Mono power 4800W
4Ω Bridge Mono power 6400W
Signal Noise Ration(dB) >80dB
THD+N(8OHM 1KHZ IN 1/4 OUTPUT) <0.05%
Damping Factor(8OHM 1K) >2000
Slew Rate >20V/us
Input sensitivity 0.775v/1.0v/1.4v
Output Circuit Class H++
Frequency Response(+/-0.1db) 20Hz-20kHz +-0.5dB
Input connectors(per ch.) 3-pin XLR, electronically balanced
Link connectors(per ch.) XLR, 3 pin male
Input Impedance 20kΩBALANCED-10kΩUNBALABCED
Output Connectors NEUTRIK
Amplifier Protection Protection of short circuit, open circuit, overheat, overload, DC, super sonic frequency etc.
Transport Dimension(CM) 3U:67.5x57x22.5cm
Net Weight 41 kgs
Gross Weight 46 kgs



Share On

Description

  • The ATI 30+ Power Amplifier delivers powerful audio performance with 2x1600W at 8Ω stereo power, 2x3000W at 4Ω stereo power, and 2x3600W at 2Ω stereo power.
  • In Bridge Mono mode, the amplifier offers 4800W at 8Ω and 6400W at 4Ω for even greater output.
  • The signal-to-noise ratio is greater than >80dB, ensuring high-quality sound with minimal distortion.
  • Featuring a Total Harmonic Distortion (THD+N) of less than 0.05% at 8Ω and 1kHz input, the amplifier provides crystal-clear sound.
  • The Damping Factor exceeds >2000 at 8Ω and 1kHz, contributing to precise low-end control and sound accuracy.
  • With a skew rate greater than 20V/μs, the ATI 30+ maintains a fast transient response for dynamic sound reproduction.
  • The amplifier offers adjustable input sensitivity options of 0.775V, 1.0V, and 1.4V to accommodate various input devices.
  • It operates with an efficient Class H++ output circuit, enhancing power efficiency while delivering high performance.
  • The frequency response spans 20Hz-20kHz ±0.5dB, providing accurate and full-range audio reproduction.
  • Input connectors are 3-pin XLR, electronically balanced for superior signal integrity, with male XLR link connectors for easy chaining.
  • The amplifier’s input impedance is 20kΩ balanced and 10kΩ unbalanced, ensuring compatibility with various sound systems.
  • Output connectors are NEUTRIK, a reliable and industry-standard choice for secure connections.
  • The amplifier protection system safeguards against short circuits, open circuits, overheating, overload, DC, and super-sonic frequencies.
  • The transport dimension measures 67.5 x 57 x 22.5 cm, fitting neatly into a 3U rack space for easy installation.
  • The amplifier has a net weight of 41 kg and a gross weight of 46 kg, making it robust yet manageable for transportation and setup.
