Description
- High Power Output: The ATI 12+ offers impressive stereo power with 2x900W at 8Ω, 2x1275W at 4Ω, and 2x1700W at 2Ω. In bridge mono mode, it provides 2550W at 8Ω and 3400W at 4Ω.
- Superior Signal Quality: Features a signal-to-noise ratio of more than 80dB, ensuring clear and distortion-free sound.
- Minimal Distortion: With a THD+N of less than 0.05% at 8Ω and 1kHz, the amplifier maintains high audio fidelity.
- High Damping Factor: The ATI 12+ has a damping factor greater than 1000 at 8Ω and 1kHz, ensuring excellent control over speakers for precise sound reproduction.
- Fast Response: With a slew rate of more than 20V/us, this amplifier offers a quick transient response for dynamic sound delivery.
- Flexible Input Sensitivity: The input sensitivity can be adjusted to 0.775V, 1.0V, or 1.4V, allowing for compatibility with different audio sources.
- Class H Output Circuit: Designed with a Class H output circuit for efficiency and reduced heat generation.
- Wide Frequency Range: The frequency response spans from 20Hz to 20kHz ±0.5dB, covering the full audio spectrum.
- Balanced Input Connectors: Equipped with 3-pin XLR electronically balanced input connectors for stable and noise-free audio transmission.
- Linking Capability: Features 3-pin male XLR link connectors for easy signal chaining with other amplifiers.
- High Input Impedance: The input impedance is 20kΩ for balanced inputs and 10kΩ for unbalanced inputs.
- Reliable Output Connectors: Uses durable Neutrik output connectors for secure and reliable speaker connections.
- Comprehensive Protection: The amplifier is protected against short circuits, open circuits, overheating, overloads, DC, and super-sonic frequencies.
- Compact and Durable Design: With a 3U transport dimension of 67.5x57x19 cm, it is compact yet robust, ideal for DJs and professionals on the go.
- Weight: The amplifier weighs 34 kg (net) and 38 kg (gross), ensuring it is both portable and built for heavy-duty use.
